Technical specification
Code of protection categories
ATEX: I M2, II 2 GD Ex d I/IIC Mb Gb, Ex e I/IIC Mb Gb, Ex tb IIIC Db, IP6X
IECEx: Ex d I/IIC, Mb/Gb, Ex e I/IIC, Mb/Gb, Ex tb IIIC Db, IP6X
CSA: Ex de IIC IP66/67/68; Class I, Division 1 and 2; Groups A, B, C, D; Class II,
Groups E, F, G; Class III; Enclosure Type 4X/6P
GOST: ExdeIU, ExdeIICU, IP66/67/68
Compliance standards
ATEX: EN 60079-0, EN 60079-1, EN 60079-7, EN 60079-31
IECEx: IEC 60079-0, IEC 60079-1, IEC 60079-31, IEC 60079-7
CSA: C22.2 No. 30-M1986 (R2012), CAN/CSA 60079-0-11, CAN/CSA 60079-1-11,
CAN/CSA 60079-7-12, CAN/CSA 60079-31:12, UL1203-5th Edition
Certificate details
ATEX: Sira 00ATEX1094X
IECEx: IECEx SIR 12.0016X
CSA: 1248014 (LR 106084)
GOST: TR RU C-GB.GB06.B.00106
Temperature
Temperature will depend on the type of o-ring used
None: -50°C to +180°C
Nitrile: -20°C to +80°C (supplied as standard)
EPDM: -30°C to +125°C
Neoprene: -20°C to +100°C
Viton: -5°C to +180°C
Silicone: -30°C to +180°C
Fluorosilicone: -50°C to +150°C
The maximum temperature is limited to +150°C for Group I applications
Ingress protection (IP):
Independently tested to IP66 / IP68 when fitted in accordance to manufacturer’s
instructions
Part number:
Please refer to page 10 for part numbering system
